ETAP QA 스탠다드
United States Code of Federal Regulation, Title 10 CFR Part 50, Appendix B
Quality Assurance Criteria for Nuclear Power Plants and Fuel Reprocessing Plants
United States Code of Federal Regulation, Title 10 CFR Part 21
Reporting of Defects and Noncompliance
United States Code of Federal Regulation, Title 10 CFR Part 50.55
Condition of Construction Permits, Early Site Permits, Combined Licenses, and Manufacturing Licenses
ANSI / ASME N45.2 – 1977
Quality Assurance Program Requirements for Nuclear Facilities
ASME NQA-1 (includes Subpart 2.7) 1994, 2000, 2008, NQA-1a 2009 addenda
Quality Assurance Requirements for Nuclear Facility Applications
IEEE 730.1 – 1995
IEEE Guide for Software Quality Assurance Planning
CAN / CSA-Q 396.1.2 – 1989
Quality Assurance Program for Previously Developed Software Used in Critical Applications
ANSI N45.2.2 – 1972
Packaging, Shipping, Receiving, Storage, and Handling of Items for Nuclear Power Plants
ISO 9001:2015
Quality Management Systems – RequirementsModel for Quality Assurance in Design, Development, Production, Installation and Servicing – ISO 9001:2015 Registered Certification Number 10002889 QM15
ETAP 검증 케이스 및 결과 비교
Arc Flash Analysis
Case No.1
Comparison of ETAP Arc Flash Results Against Hand Calculated Results Based on IEEE Standards
Case No.2
Verification from ETAP Arc Flash NFPA 70E Results Against Hand Calculations
Load Flow Analysis
Case No.1
Comparison of ETAP Load Flow Results Against a Published Textbook Example
Case No.2
Comparison of ETAP Load Flow Results Against a Published Example
Case No.3
Comparison of ETAP Load Flow Results Against a Published Textbook Example
Motor Starting Analysis
Case No.1
Comparison of ETAP Motor Starting with Torque Control Against Hand Calculated Results
Case No.2
Comparison of ETAP Motor Starting Results Against Transient Stability
Short Circuit Analysis – ANSI / IEEE
Case No.1
Comparison of Short-Circuit Results Against Hand Calculations Based on Application Engineering Information
Case No.2
Comparison of ETAP Unbalanced Short-Circuit Calculations Against a Published Example
Case No.3
Comparison of ETAP 3-Phase Duty Short-Circuit Calculations against Published IEEE Std 399-1997 Example
Transient Stability Analysis
Case No.1
Comparison with Field Measurement Data for Generator Start-Up Condition
Case No.2
Comparison with I.E.E. Japan (IEEJ) Electrical Power System Standard Benchmark
Case No.3
Comparison with Field Measurements from a Digital Fault Recorder
Case No.4
Comparison with 9-Bus Multi-Machine System Benchmark
Case No.5
Comparison with PTI PSS/E Simulation Results
Harmonic Analysis
Case No.1
Comparison of ETAP Harmonic Analysis Results Against an IEEE Example
Short Circuit Analysis – IEC
Case No.1
Comparison of ETAP Short-Circuit IEC Calculations Against Published Example
Unbalanced Load Flow
Case No.1
Comparison of ETAP Unbalanced Load Flow Results Against a Published IEEE 13-Bus Feeder System
